Valmet 5000 Flanged Ball Valve, 1/2in CS
Series 5000 1/2" Flanged Ball Valve. Standard Bore Class 150 with Carbon Steel (WCB) Body, XTREME Seat, Molecularly Enhanced PTFE Seal, and 316 Stainless Steel Ball and Stem. Raised Face Non-Fire-Tite, Non-Trunnion End Connection Construction. 450psi.
The Jamesbury polymeric-seated flanged ball valve provides reliable bi-directional shutoff. Double-Seal design uses a unique flexible lip to seal against the ball and provide long-lasting shut-off in either direction. Bubble-Tight Shut-off: exceeds ANSI/FCI 70-2 Class VI Level. High Flow Capacity. Standard-port design offers high flow capacity for control of clean or dirty fluids and gases, including steam. XTREME seat provides longer life, expanded performance boundaries, and greater value. Superior control characteristics, coupled with tight shut-off capabilities, make this valve ideal for a variety of on-off and control applications.
